Description:
This product is designed at small size with less area demand in kiosks, adopts industrial design, good resistance to abrasionand corrosion, fit for high or low temperature and dusty environments.Six shifts card space adjustment is our patented technologyused for issuing cards with different thickness, and CNC precision ensures absolute unanimity of card space.Fundamentally prevent 2 card dispensing with unique clutch system.
Features:
- Sound alarmwhenthere areno cards orfew cards.
- Preventing dispensing double card simultaneously: Up gear and down gear swirl in different
- direction, and friction dispensing card can avoid dispensing double card at the same time,even suitable to some distorted cards.
- Can issue cards in the stacker in normal condition.Most distorted cards can be issued byusing card holder.
- Especially suitable for issuing thin paper cards, and card dispenser can also be set accoding to customer’s requirement.
- Card thickness adjustment is convenient, precise and easy to operate.TTL and RS232 control interface (optional)
- Pre-dispensing function accelerates the speed and ensures the continuous card issuing.
Specifications:
| Operation Power | DC 24 V (MAX CURRENT 2A, Static current100mA), |
| Operation Temp. | 20 ℃ ~ 85 ℃ |
| Operation Humi. | 30~90%(Relative Humidity) |
| Interface | RS232 |
| Operation Condition | Install in the cabinet, control by protocol commend |
| Card Size | Width: 54 ± 0.5 mm Length : 85 ± 0.5 mm Thickness: 0.2~2.0 mm (adjustable) |
| Card Material | Paper card and PC card |
| Alarm | 7~50pcs(preset 15pcs of 0.76mm thick cards) |
| Card stacker capacity | 190pcs standard cards based on the thickness of 0.76 mm |
| Install dimension | Refer to attached product structure figure |
| Machine Net weight | 2.0KG(Including card holder ) |
