Features:
- Industrial design with excellent abrasion and corrosion resistance, suitable for high or low temperatures and dusty environments.
- The body is metal material,and the channel is plastic material,Supports 13.56Mhz RFID smart card reading writing,Reserves the RFID card reading module install position.
- By changing the channel space can accept all the card thickness between 0.7-1.0mm
- Max loading 300pcs card thickness 0.76mm compare standard 150pcs cards
- Card empty and pre-empty detect function and sound alarm
- RS232 control interface,supports multiple device communication
- SDK/DLL/Demo software for Windows,Limux and Android.
Specifications:
| Subject | Content |
| Operation power | 24VDC (Max current 2A, static current 0.1A) |
| Operation temperature | -20 ℃ to 85 ℃ |
| Operation humidity | 30-90% （RH） |
| Interface | RS232 |
| Card stay position | Multiple card stay position control |
| Operation condition | Install in the cabinet |
| Card size | Width: 54 ± 0.5 mm Length : 85 ± 0.5 mm Thickness： 0.2 – 2.0mm Adjustable Card material：paper card or polyester card |
| Stacker capacity | 150pcs standard cards based on the thickness of 0.76 mm |
| Few card Alert | 7~50pcs（0.76mm thick，Preset qty is 15pcs） |
| Install dimension | Refer to product structure drawing |
| N.W | 2.0Kg（Include card holder） |
