Overview:
DP-58L is one 58mm desktop thermal label printer, which is specially designed for thermal sticker printing. It can support both normal thermal paper and thermal label paper. 1D and 2D barcode printing are both supported. Multiple interfaces including USB +LAN/RS232/Bluetooth for option. SDK/Driver for Windows/MAC/Android/IOS are available.
Features:
- Easy paper loading
- USB/RS232/LAN/Bluetooth communication interface for option
- Up to 90mm/s high speed printing
- Support multi languages
- Support 1-D and 2-D barcode, graphic printing
- Compatible with TSPL/ESC/POS commands
- Provide SDK/Driver for Windows/MAC/Android/IOS
Applications:
Retail and Catering industry for Label sticker printing and Order management
Specifications:
| Print Method | Direct Line Thermal |
| Interfaces | USB +(LAN/RS232/Bluetooth)optional |
| Print Comand | TSPL / ESC / POS |
| Print Speed | 50-90 mm/s |
| Resolution | 203DPI (8dot/mm) |
| TPH Reliability | 50km (25% printing density or less) or per dot: 100 million pulses |
| Inner Code | ASCII font library (8×16, 12×24, 16×32, 24×48), GBK (16×16), GB1830 (24X24) |
| Print content | English, Numbers, Various symbols, Chinese characters, Graphics, Curves, Pre-stored icons |
| Supported Code | 1D: UPC-A / UPC-E / JAN13 (EAN13) / JAN8 (EAN8) / CODE39 / ITF / CODABAR / CODE93 / CODE128 2D: QR CODE |
| Electrical | |
| Charging Method | AC 100-240v 50\60Hz;DC 9V 2A |
| Paper | |
| Paper Types | Thermal Roll Paper,label paper |
| Available Rang of Paper Width | 15-48mm; |
| Roll DiameterAvailable Printing Width | φ≤83mm |
| Paper Thickness | 0.06-0.20 mm |
| Physical | |
| Printer Dimension | 160*120*126mm |
| Printer N.W. | 720g |
| Printer Color | White / Black |
| Environmental Requirements | |
| Work Environment | Temperature (0～50℃) humidity(20～85%) |
| Storage Environment | Temperature(-20～60℃) humidity(5～95%) |
| Accessories | |
| USB Cable | 1 Piece |
| User Manual | 1 Piece |
| Cardholder | 1 Piece |
| Power Adapter | 1 Piece |
