Key Features
-
High-Speed Processing: Powered by an Octa-core 2.0GHz 64-bit processor for seamless multi-tasking.
-
Advanced Data Capture: Integrated top-tier 1D/2D barcode scanning engine and optional long-range UHF RFID reader (0-3m).
-
Rugged Construction: IP68-rated for water and dust resistance, with a high-strength Gorilla Glass touch screen for drop protection.
-
Ultra-Long Battery Life: 6000mAh large-capacity polymer battery with fast-charging support, designed for full-shift operation.
-
Superior Connectivity: Reliable 4G LTE, dual-band Wi-Fi (2.4G/5.8G) with seamless roaming, and Bluetooth 4.2.
-
Multi-Functional Modules: Supports NFC, high-resolution 16MP camera for documentation, and professional ID card identification.
Applications
-
Warehouse Management: Real-time stocktaking, outbound/inbound tracking, and asset management.
-
Express & Logistics: Fleet management, package scanning, and proof of delivery.
-
Retail & Inventory: Price checking, shelf management, and mobile point-of-sale.
-
Public Utilities: Identity verification, meter reading, and field service data collection.
Technical Specifications
| Category | Item | Specifications |
| System | OS | Android 11.0 |
| CPU | MT6762 Octa-core 2.0GHz 64-bit | |
| Memory | 4GB RAM + 64GB ROM (Standard) / 6GB + 128GB (Optional) | |
| Display | Screen | 5.5″ IPS Gorilla Glass (1440 x 720) |
| Touch | Multi-touch capacitive industrial-grade screen | |
| Battery | Capacity | 3.8V 6000mAh Polymer Lithium Battery |
| Charging | < 3 hours (Supports 9V/1.6A Fast Charge) | |
| Wireless | Network | 4G / 3G / 2G Full Band |
| Wi-Fi | 802.11 a/b/g/n/ac (2.4G/5.8G Dual Band) | |
| Bluetooth | BT 4.2 | |
| GPS | GPS / Galileo / Glonass / Beidou | |
| Data Capture | Barcode | 1D/2D CMOS Imager (Zebra SE4710 / HS7) |
| UHF RFID | 915MHz / 865MHz (Range: 0 – 3m) | |
| NFC | 13.56MHz (Range: 5 – 10cm) | |
| Camera | Front / Back | 5.0MP Front / 16.0MP Back with AF & Flash |
| Physical | Dimensions | 158 x 76 x 19.5 mm |
| Weight | 380g | |
| IP Grade | IP68 | |
| User Env. | Temp | Operating: -20°C to 50°C / Storage: -20°C to 70°C |
