Thermal Panel Printer Features:
1.Smart panel size
2.Convenient for handling
3.Wide voltage range(5-8.5V or 9-24V for option)
4.Easily embedded to any kinds of instruments and meters
Thermal Panel Printer Specification:
| Printing Method | Thermal Line | |
| Printing Speed | 30mm/s | |
| Resolution | 8 dots/mm(203dpi), 384 dots/line | |
| Effective Printing Width | 48mm | |
| Character | Character Set | ASCII, GB18030(Chinese), BIG5 |
| Print Font | Font A: 12×24 Font B:8×16 | |
| Paper Spec | Paper Type | Thermal paper |
| Paper Width | 57.5± 0.5mm | |
| Paper Thickness | 0.06~0.08mm | |
| Paper Roll Diameter | D8A Max: 20.0mm, D8B Max: 30.0mm, D8C Max:50.0mm | |
| Barcode | UPC-A，UPC-E，EAN-13，EAN-8，CODE39，ITF25，CODEBAR，CODE93，CODE128 | |
| Emulation | ESC/POS | |
| Driver | Windows98/2000/NT/XP/Vista/Win7 | |
| Interface | D8A:RS-232/Parallel/TTL/RS485 | |
| D8B&D8C: RS232/Parallel/TTL/RS485/USB | ||
| Paper Supply Method | Drop-in easy paper loading | |
| Power Supply (Adapter) | DC5V-8V, 3A / DC9-24V 2A | |
| Printer Mechanism | Own brand | |
| Physical | Outline Dimension(WxHxD) | D8A: 79.5x42x39.5mm; D8B: 83×58.5×45.5mm; |
| D8C: 85x85x57.5mm | ||
| Installation PortSize(WxHxD) | D8A: 75.5×38.5x37mm; D8B: 78.5x54x43mm; | |
| D8C: 80.5×80.5×55.5mm | ||
