- Fully integrated printer mechanism, presenter and PCB architecture
- Varying ticket lengths – to meet Sports Betting requirements.
- Independent Full or partrial cutting by adjustable.
- Maximum Print Speed of 250mm per second.
- Resolution 203 dpi – 8 dots/mm.
- Special print scalable to 8x with reverse, underscore, italic, and bold print
- 48/64 characters per line for 80 mm paperwidth (12*24/9*17)
- Ticket with Face-up printing
- ASCII character encoding
- Ladder and fence barcode printing supporting UPC-A, UPC-E, EAN13, EAN8, Code39, ITF, CODABAR, Code93, Code 128, Code31
- Serial RS232C and USB interfaces built into main controller PCB
- Selectable baud rates
- Windows & Linux Driver Support
- 4 MB minimum flash memory and 64KB RAM (extensible 256kB RAM)
- EPSON emulation
- Power: 24 VDC
- Paper Out, Paper Cover-Open, Paper Low, Top-Of-Form, Jam Detection, Transport Ticket Taken, Head Temperature.
- Ticket blocked detection system
- Power and error LED(s)
- Paper feed button
- Easy paper feed/loading with auto-cut
- Portrait or landscape mode
- Paper width Options: 60mm, 80mm and 82.5mm
- RoHS /CE Compliant
- Bezel assembly with LEDs (Colour Options available –
- subject to agreement)
- Universal paper roll spindle (60mm, 80.0mm &
- 82.5mm.)
- Printer head easily accessed for quick and easy maintenance.
- Paper roll tensioner to handle larger paper rolls
- 60mm and 80mm paper guides
- Larger core spindle sleeve
- Front/Top Paper roll loading – kit
- Standard 3 way PSU/Serial/USB cable set
- Optinal PSU/Serial or PSU/USB cable set (left or right)
Kiosk Thermal Printer Applications:
- Self-service inquiry terminal
- Queuing machine
- ATM
- Lottery printing
- Log printing
- Self-service call bill printer
- Self-service invoice printing
|
Thermal printer head |
Brand name: ROHM |
||||
|
Auto cutter |
Brand name: OYANE |
||||
|
Printing
|
Printing method |
Thermal dot line |
|||
|
Dots |
640dots |
||||
|
Speed |
250mm/s (max) |
||||
|
Printing width |
80mm (max) |
||||
|
Paper width |
80/82.5 mm |
||||
|
Paper roll diameter |
120mm(Max) |
160mm(Max) |
|||
|
Paper thickness |
0.06~0.2 mm |
||||
|
Paper loading |
Auto paper loading ( horizontal 180°) |
||||
|
Cutting method |
Full/partial by commands |
||||
|
Print head life |
Over 100KM |
||||
|
Printing format |
inverse,underline,italic,bold |
||||
|
Cutter life
|
60μm paper |
1,000,000 cuts |
|||
|
200μm paper |
500,000 cuts |
||||
|
|
Baud rate |
9600,19200,38400,115200 |
|||
|
Font |
ASCII |
9*17,12*24 |
|||
|
Chinese |
24*24dots |
||||
|
Detection |
TPH temperature |
Temperature sensor |
|||
|
Mechanism open detection |
Micro switch |
||||
|
Paper presence detection |
Mechanical sensor |
||||
|
Ticket out detection |
|||||
|
Paper near end detection |
Photo-interrupter |
||||
|
Black mark detection |
|||||
|
Paper cutting detection |
|||||
|
Paper retracting detection |
|||||
|
Condition |
Power supply |
DC24±10% V |
|||
|
Load current |
1.5A continuous 61mA Standby 3.2 A Peak |
||||
|
Interfaces |
RS232,USB |
||||
|
Paper |
Paper type |
Thermal paper roll | |||
|
Recommended paper type |
KANZAN KF50
KP460 MITSUBISHIPG5075 TL4000 |
||||
|
Environment |
operating temperature |
-10~60℃(no condensation) |
|||
|
operating humidity |
20%~80%RH(40℃,85%RH) |
||||
|
Storage temperature |
-20~70℃(no condensation) |
||||
|
Storage humidity |
10%~90%RH(50℃,90%RH) |
||||
|
physics |
Dimension |
L*W*H=230.97*123.3*100.25 mm (Paper holder horizontal (without paper roll) |
|||
|
Net Weight |
Approx 1.15kg(product itself) |
||||
