SNR-KP347-TL Self-Service Kiosk Printer
SNR-KP347-TL is an 80mm embedded self-service kiosk printer designed for lottery machines, payment kiosks, information machines, parking systems, queue management kiosks, ATMs and ticket vending machines. It features CAPD347 thermal mechanism, 170mm/s printing speed, 72mm print width, auto cutter, paper ejector, anti-jam and anti-pull paper handling, paper end detection, black mark detection, RS232 + USB interfaces, ESC/POS command set, barcode support and Windows / Linux / Android integration.
"*" indicates required fields
80mm Embedded Thermal Printer for Lottery Machines, Payment Kiosks and Self-Service Terminals
The SNR-KP347-TL is an 80mm embedded thermal printer designed for lottery machines, payment kiosks, information terminals, parking systems, queue management kiosks, ATMs, gas station kiosks and ticket vending machines.
Built with a CAPD347 thermal printer mechanism, auto cutter, paper ejector function, anti-jam paper protection, anti-pull paper detection, black mark detection and RS232 + USB interfaces, SNR-KP347-TL provides reliable receipt and ticket output for unattended self-service applications.
With a cutter lifetime of over 7,000,000 cuts, thermal head life over 100km and MCBF of 37,000,000 lines, this printer is suitable for high-frequency public terminal deployments where long service life and stable output are important.
Key Features
- 80mm embedded self-service kiosk printer
- Designed for lottery machines and self-service terminals
- CAPD347 thermal printer mechanism
- Thermal dot line printing
- 576 dots per line
- 8 dots/mm resolution
- 72mm printing width
- Supports large paper roll up to Ø150mm
- Printing speed up to 170mm/s
- Auto paper feed
- Auto cutter
- Paper ejector function
- Anti-jam paper protection
- Anti-pull paper detection
- Paper end detection
- Black mark detection
- Easy paper loading
- Multiple mounting brackets for flexible installation
- RS232 + USB interfaces
- ESC/POS command set
- Barcode printing supported
- Windows / Linux / Android OS support
- Low consumable cost with thermal paper
Applications
- Lottery machines
- Gaming terminals
- Payment kiosks
- Information machines
- Parking systems
- Queue management kiosks
- ATMs
- Gas station kiosks
- Ticket vending machines
- Multimedia kiosks
- Self-service terminals
- Public service kiosks
- Transportation ticket machines
- Retail service kiosks
- Banking self-service terminals
Technical Specifications
Printing Specifications
| Item | Specification |
|---|---|
| Model | SNR-KP347-TL |
| Product Type | 80mm Embedded Self-Service Kiosk Printer |
| Mechanism | CAPD347 |
| Printing Method | Thermal dot line printing |
| Dots Per Line | 576 dots/line |
| Dot Pitch | 8 dots/mm |
| Paper Width | 80mm |
| Paper roll diameter | 150mm |
| Paper Thickness | 54–78μm |
| Printing Speed | 170mm/s |
| Paper Feed Direction | 180° horizontal |
| Paper Loading | Easy loading |
| Command Set | ESC/POS |
| Barcode | Supported |
Fonts
| Item | Specification |
|---|---|
| ASCII Font | 9 × 17, 12 × 24 |
| Chinese Font | 24 × 24 |
Sensor Functions
| Sensor Item | Specification |
|---|---|
| Head Temperature | Thermistor |
| Paper Press Shaft | Mechanical switch |
| Paper End | Photo interrupter |
| Paper Near-End Sensor | Accessory option |
| Paper Jam Sensor | Accessory option |
| Dragging Paper Sensor | Accessory option |
Electrical Specifications
| Item | Specification |
|---|---|
| Logic Circuit Power | 4.75–5.25V |
| Motor Power | 21.6–26.4V |
| Power Supply | DC24V / 2.5A |
| Interface | RS232 + USB |
Controller and Memory
| Item | Specification |
|---|---|
| Firmware Location | 512KB Flash memory |
| Buffer | 32KB |
| SRAM | 64KB extra |
| Driver | Parallel / USB driver |
| Supported OS | Windows / Linux / Android |
Reliability
| Item | Specification |
|---|---|
| Circuit Life | Over 1,000,000,000 pulses |
| Cutter Life | Over 7,000,000 cuts |
| Thermal Head Life | Over 100km |
| MCBF | 37,000,000 lines |
Environmental Specifications
| Item | Specification |
|---|---|
| Operating Temperature | -10℃ to 50℃ |
| Operating Humidity | 20%–85% RH |
| Storage Temperature | -25℃ to 70℃ |
| Storage Humidity | 10%–90% RH |
Mechanical Specifications
| Item | Specification |
|---|---|
| Dimensions | 186.9 × 121.5 × 112.2mm |
| Weight | Approx. 1.2kg, without paper roll |
Why Choose SNR-KP347-TL?
SNR-KP347-TL is suitable for self-service systems that require 80mm ticket or receipt printing, reliable paper output and long cutter life.
Compared with basic thermal printer modules, KP347-TL provides anti-jam paper handling, anti-pull paper detection, paper ejector function, black mark detection, auto cutter, flexible mounting brackets and RS232 + USB interfaces. These features make it practical for lottery machines, payment kiosks, parking systems, ATMs, queue management terminals and ticket vending machines.
For projects requiring an 80mm embedded kiosk printer with strong durability and reliable unattended operation, SNR-KP347-TL provides a professional self-service printer solution.
Related Models
SNR-KP803 – 80mm embedded self-service terminal thermal printer with 300mm/s speed and side-flip cover
SNR-KP805 – 80mm kiosk thermal printer module for banking, parking and queuing systems
SNR-KP800-TU – 80mm high-speed kiosk thermal printer with anti-paper blocked and anti-drag ticket systems
SNR-KP800-TH – 80mm auto cutter thermal receipt printer for POS, kiosk and retail applications
SNR-KP802-VX – Heavy-duty 80mm kiosk printer for unattended self-service systems
Related Resources
- Kiosk Printer Hub
- How to Choose a Kiosk Printer in 2026
- Kiosk Printer Buying Guide
- Presenter Printer vs Auto Cutter Printer
- 58mm vs 80mm Kiosk Printer
- Presenter kiosk printer for parking systems
- Why Kiosk Printers Jam in Real Self-Service Deployments
- Why Maintenance Accessibility Matters in Self-Service Kiosk Design
- Parking Ticketing Solutions
- Queue Management System Hardware
- Self-Checkout Hardware Solutions
- Visitor Management Kiosk Solutions
- How to Choose a Kiosk Printer for Ticket Vending Machines
- How to Choose a Kiosk Printer for Banking Self-Service Terminals
- Linux Kiosk Printer Integration Guide
- Kiosk Printer SDK Guide
- Why Paper Roll Capacity Matters More Than Many Teams Expect
FAQ
What is SNR-KP347-TL used for?
SNR-KP347-TL is used as an 80mm embedded self-service kiosk printer for lottery machines, payment kiosks, information terminals, parking systems, queue management kiosks, ATMs, gas station kiosks and ticket vending machines.
What printer mechanism does SNR-KP347-TL use?
It uses the CAPD347 thermal printer mechanism.
What paper width does it support?
It supports 80mm paper width.
What is the maximum printing width?
The maximum printing width is 72mm.
What is the printing speed?
The printing speed is 170mm/s.
Does SNR-KP347-TL support auto cutting?
Yes. It supports auto cutting and has a cutter lifetime of over 7,000,000 cuts.
Does it support anti-jam and anti-pull paper protection?
Yes. It includes anti-jam paper and anti-pull paper functions for more stable unattended operation.
Does it support black mark detection?
Yes. Black mark detection is supported.
What interfaces are available?
SNR-KP347-TL supports RS232 + USB interfaces.
Is barcode printing supported?
Yes. Barcode printing is supported.
What operating systems are supported?
It supports Windows, Linux and Android OS integration.
Is there a model with ticket presenter?
For projects requiring the same quality 80mm kiosk printer with ticket presenter, the WP80-TMP model can be considered.
