SNR-KP800-VX 80mm Kiosk Industrial Thermal Printer
The SNR KP800-VX is a fully integrated, high-performance kiosk thermal printer designed for demanding self-service environments. With a maximum print speed of 250mm per second, it is ideal for applications requiring fast, reliable ticket and receipt output, such as queuing systems, parking terminals, ATMs, and sports betting kiosks.
The printer features a compact design with rear paper loading, auto-loading, and an auto-cutter. It includes RS232, USB, and Ethernet interfaces as standard, plus an independent power switch for safer maintenance. Its clean paper path and comprehensive sensor suite ensure high reliability and minimal operator intervention.
"*" indicates required fields
80mm Kiosk Thermal Printer with RS232, USB and Ethernet Interface for Parking, ATM, Queue and Ticketing Systems
The SNR-KP800-VX is a fully integrated, high-performance 80mm kiosk thermal printer designed for demanding self-service environments. With a maximum print speed of 250mm/s, it is ideal for applications requiring fast and reliable ticket or receipt output, such as queuing systems, parking terminals, ATMs, gaming machines and sports betting kiosks.
The printer features a compact structure with rear paper loading, auto paper loading and an auto cutter. It supports RS232, USB and Ethernet interfaces, plus an independent power switch for safer maintenance. Its clean paper path and comprehensive sensor suite help ensure high reliability, reduced downtime and minimal operator intervention in unattended kiosk deployments.
Features
- Fully integrated kiosk printer design
- Combines printer mechanism, presenter and main PCB in a compact architecture
- High-speed thermal printing up to 250mm/s
- High resolution: 203 dpi, 8 dots/mm
- Supports 80mm and 82.5mm paper width
- Supports 60mm paper guide option
- Large paper roll capacity up to 160mm
- Rear paper feed with horizontal 180° auto paper loading
- Auto cutter with full cut and partial cut by command
- Independent power switch for safer maintenance
- RS232, USB and Ethernet interface support
- EPSON-compatible emulation
- Windows and Linux driver support
- Easy printhead access for cleaning and maintenance
- Comprehensive detection functions
- Supports paper out, cover open, paper low, ticket out, ticket blocked and ticket taken detection
- Supports black mark detection and paper cutting detection
- Supports barcode printing
- RoHS and CE compliant
Applications
- Self-service inquiry terminals
- Queue management systems
- Queuing / ticketing machines
- ATMs
- Banking self-service terminals
- Lottery printing terminals
- Log printing systems
- Self-service bill and invoice printing
- Sports betting terminals
- Parking payment terminals
- Gaming machines
- Ticket vending machines
- Visitor management kiosks
- Self-service information kiosks
Typical Deployment Scenarios
Parking Payment Kiosks
SNR-KP800-VX is suitable for parking payment and access control systems where reliable ticket issuance, stable cutting and unattended operation are required.
Queue Management Systems
The printer can be integrated into queue ticket machines used in banks, hospitals, government service centers and customer service environments.
Ticket Vending Machines
With high-speed printing, auto paper loading and large paper roll support, SNR-KP800-VX is suitable for ticket vending systems that require stable output and easy maintenance.
Banking Self-Service Terminals
The printer supports receipt printing and transaction ticket output in banking self-service terminals and ATM-related equipment.
Self-Service Information Kiosks
SNR-KP800-VX can be used in visitor management, service registration, information inquiry and customer interaction terminals.
Visitor Management System Hardware
SNR-KP800-VX can be integrated into visitor management kiosks and registration terminals for visitor ticket, badge or receipt printing, supporting stable output, auto cutting and unattended front-desk operation.
Options Available
- 60mm and 80mm paper guides
- Larger core spindle sleeve
- Front / top paper roll loading kit
- Standard 3-way cable set: PSU / Serial / USB
- Optional PSU / Serial cable set
- Optional PSU / USB cable set
- Left or right cable set options
- LED bezel assembly with color options available
- Ethernet communication option depending on project configuration
Technical Specifications
Printer Module
| Item | Specification |
|---|---|
| Model | SNR-KP800-VX |
| Product Type | 80mm kiosk industrial thermal printer |
| Printer Head Brand | ROHM |
| Auto Cutter Brand | OYANE |
| Emulation | EPSON compatible |
| Compliance | RoHS / CE |
Printing Specifications
| Item | Specification |
|---|---|
| Printing Method | Thermal dot line printing |
| Dots | 640 dots |
| Resolution | 8 dots/mm, 203 dpi |
| Printing Speed | 250mm/s max |
| Printing Width | 80mm max |
| Paper Width | 80mm / 82.5mm |
| Optional Paper Guide | 60mm |
| Paper Roll Diameter | 120mm max / 160mm max |
| Paper Thickness | 0.06–0.2mm |
| Paper Loading | Auto paper loading, horizontal 180° |
| Cutting Method | Full cut / partial cut by command |
| Print Head Life | Over 100km |
| Printing Format | Inverse, underline, italic, bold |
Cutter Life
| Paper Thickness | Cutter Life |
|---|---|
| 60μm paper | 1,000,000 cuts |
| 200μm paper | 500,000 cuts |
Fonts and Barcode Support
| Item | Specification |
|---|---|
| ASCII Font | 9 × 17, 12 × 24 |
| Chinese Font | 24 × 24 dots |
| Supported Barcode Types | UPC-A, UPC-E, EAN13, EAN8, Code39, ITF, CODABAR, Code93, Code128, Code31 |
| Barcode Direction | Ladder and fence barcode supported |
Communication and Interface
| Item | Specification |
|---|---|
| Standard Interfaces | RS232, USB |
| Ethernet | Supported / optional depending on configuration |
| Baud Rate | 9600, 19200, 38400, 115200 |
| Driver Support | Windows / Linux |
| SDK | Available upon request |
Detection Functions
| Detection Item | Specification |
|---|---|
| TPH Temperature Detection | Temperature sensor |
| Mechanism Open Detection | Micro switch |
| Paper Presence Detection | Mechanical sensor |
| Ticket Out Detection | Supported |
| Paper Near-End Detection | Photo-interrupter |
| Black Mark Detection | Supported |
| Paper Cutting Detection | Supported |
| Paper Retracting Detection | Supported |
| Ticket Blocked Detection | Supported |
| Ticket Taken Detection | Supported |
| Jam Detection | Supported |
Power Specifications
| Item | Specification |
|---|---|
| Power Supply | DC24V ±10% |
| Continuous Load Current | 1.5A |
| Standby Current | 61mA |
| Peak Current | 3.2A |
| Maintenance Safety | Independent power switch |
Paper Specifications
| Item | Specification |
|---|---|
| Paper Type | Thermal paper roll |
| Recommended Paper | KANZAN KF50, KP460, MITSUBISHI PG5075, TL4000 |
Environmental Specifications
| Item | Specification |
|---|---|
| Operating Temperature | -10℃ to 60℃, no condensation |
| Operating Humidity | 20%–80% RH |
| Storage Temperature | -20℃ to 70℃, no condensation |
| Storage Humidity | 10%–90% RH |
Physical Specifications
| Item | Specification |
|---|---|
| Dimensions | 230.97 × 123.3 × 100.25mm |
| Dimension Description | Paper holder horizontal, without paper roll |
| Net Weight | Approx. 1.15kg, product itself |
Software & Integration Support
The SNR-KP800-VX is designed to simplify integration into self-service kiosk projects.
- Windows driver support
- Linux driver support
- USB communication
- RS232 communication
- Ethernet interface support depending on configuration
- SDK and technical documentation available
- Engineering support during integration
Why Integrators Choose SNR-KP800-VX
The SNR-KP800-VX is designed for self-service applications that require reliable ticket printing, compact integration and long-term unattended operation. Many kiosk manufacturers and system integrators select this model for projects where maintenance efficiency and deployment reliability are critical.
Compared with basic embedded receipt printers, SNR-KP800-VX provides a more complete kiosk printer structure with auto paper loading, auto cutter, large paper roll support, multiple sensor detection and flexible communication interfaces.
Main advantages for system integrators:
- Compact design for easier kiosk integration
- Reliable thermal printing for unattended environments
- 250mm/s high-speed printing for faster transaction output
- Large paper roll support to reduce refill frequency
- RS232, USB and Ethernet communication options
- Windows and Linux support for easier system integration
- Suitable for parking, ticketing, banking and queue management applications
- Maintenance-friendly structure for long-term operation
- Easy printhead access for cleaning and replacement
What Experienced Integrators Usually Evaluate
- Paper roll capacity
- Maintenance accessibility
- Expected print volume
- Linux compatibility
- SDK availability
- Network connectivity
- Deployment environment
- Service accessibility
- Long-term reliability
This evaluation process often has a greater impact on deployment success than print speed alone.
Related Resources
- Kiosk Printer Hub
- How to Choose a Kiosk Printer in 2026
- Kiosk Printer Buying Guide
- Why Kiosk Printers Jam in Real Self-Service Deployments
- Presenter Printer vs Auto Cutter Printer
- 58mm vs 80mm Kiosk Printer
- Why Maintenance Accessibility Matters in Self-Service Kiosk Design
- Parking Ticketing Solutions
- Queue Management System Hardware
- Self-Checkout Hardware Solutions
- Banking Self-Service Terminal Hardware Solutions
- How to Choose a Kiosk Printer for Banking Self-Service Terminals
- How to Choose a Kiosk Printer for Ticket Vending Machines
- Why Paper Roll Capacity Matters More Than Many Teams Expect
- Linux Kiosk Printer Integration Guide
- Kiosk Printer SDK Guide
Related Models
SNR-KP802-VX – High-end 80mm kiosk thermal printer with presenter and optional ticket retract
SNR-KP807 – 80mm kiosk thermal printer module for ATM, vending and parking systems
SNR-KP803 – 80mm embedded self-service terminal thermal printer with 300mm/s speed
SNR-KP800-TU – 80mm high-speed kiosk thermal printer with anti-paper blocked and anti-drag ticket systems
SNR-KP805 – 80mm kiosk thermal printer module for banking, parking and queuing systems
Related Technical Downloads
- Kiosk Printer Linux Driver & SDK
- Kiosk Printer Windows Driver
- SDK Resources
- User Manuals
- CAD Drawings
Frequently Asked Questions
Does SNR-KP800-VX support Linux?
Yes. Linux support is available for most kiosk integration projects.Please read Linux Kiosk Printer Integration Guide.
Do you provide SDK resources?
Yes. SDK resources and integration documentation are available upon request. Please visit our SDK & Drivers Center.
Is the printer suitable for parking systems?
Yes. Parking payment and ticketing applications are among the most common deployment scenarios for this model.Please Learn more about Parking Ticketing Solutions.
Can SNR-KP800-VX be integrated into queue management systems?
Yes. It is suitable for queue ticket printing and customer service applications in banks, hospitals, government service centers and other public service environments.Please See Queue Management System Hardware.
What communication interfaces are available?
The printer supports USB, RS232 and Ethernet interface options depending on project configuration.
What paper width does it support?
It supports 80mm and 82.5mm paper width. A 60mm paper guide option is also available.
What is the maximum paper roll diameter?
The printer supports paper roll diameter up to 160mm, helping reduce paper replacement frequency in unattended terminals.
Does it support black mark paper?
Yes. Black mark detection is supported.
Does it support barcode printing?
Yes. It supports common 1D barcode types including UPC-A, UPC-E, EAN13, EAN8, Code39, ITF, CODABAR, Code93, Code128 and Code31.
What maintenance is typically required?
Periodic cleaning and inspection are recommended to ensure long-term operational reliability, especially in high-volume or dusty environments.
Is SNR-KP800-VX suitable for banking self-service terminals?
Yes. The KP800-VX is commonly used in banking kiosks, financial service terminals, and ATM-related applications requiring reliable receipt printing and long-term unattended operation.Learn more about Banking Self-Service Terminal Hardware Solutions.
Can KP800-VX be used in ticket vending machines?
Yes. The printer is suitable for ticket vending systems that require stable ticket output, large paper roll capacity, and easy maintenance.Learn more about Ticket Vending Machine Hardware Solutions.
