SNR-KP800-TH Auto Cutter Thermal Receipt Printer
SNR-KP800-TH is a high-speed 80mm auto cutter thermal receipt printer designed for POS systems, self-service kiosks, retail checkout, hospitality terminals, banking systems and ticketing applications. It features 250mm/s printing speed, 203 dpi resolution, 72mm print width, 60 / 80 / 82.5mm paper support, 150mm paper roll capacity, USB and RS232 interfaces, optional Ethernet / Bluetooth, ESC/POS compatibility, paper-low / paper-end / cover-open sensors, 1.5 million-cut cutter life and 150km print head life.
"*" indicates required fields
80mm High-Speed Thermal Receipt Printer for POS, Kiosk and Retail
The SNR-KP800-TH is a high-performance 80mm thermal receipt printer designed for POS systems, self-service kiosks, retail checkout counters, hospitality terminals, queuing systems and unattended transaction environments.
With high-speed printing up to 250mm/s, an industrial auto cutter, ESC/POS compatibility, USB and RS232 interfaces, optional Ethernet / Bluetooth connectivity and support for large paper rolls up to 150mm, SNR-KP800-TH provides fast and reliable receipt output for high-volume commercial applications.
Its robust structure, paper-low detection, front drop-in paper loading and long-life print head make it suitable for both staffed and unattended service scenarios.
Key Features
- 80mm thermal receipt printer
- High-speed printing up to 250mm/s
- Direct thermal line printing
- 203 dpi resolution, 8 dots/mm
- Print width up to 72mm
- Supports 60mm / 80mm / 82.5mm paper width
- Supports paper roll diameter up to 150mm
- Automatic paper feeding, horizontal 180°
- Industrial auto cutter
- Partial cut or full cut supported
- Auto cutter life over 1.5 million cuts
- Print head life up to 150km
- MTBF up to 360,000 hours
- USB and RS232 serial interfaces
- Ethernet optional
- Bluetooth optional
- ESC/POS compatible
- Paper low, paper end and cover open sensors
- Multi-language and multi-character set support
- Front drop-in paper loading for easy maintenance
- Designed for POS, kiosk, retail and unattended operation
Applications
- Retail POS systems
- Self-checkout terminals
- Staffed checkout counters
- Price checker kiosks
- Return and exchange counters
- Self-ordering kiosks
- QSR and restaurant terminals
- Drive-thru confirmation printing
- Kitchen order ticket printing
- Customer queuing systems
- Ticketing kiosks
- Patient check-in kiosks
- Parking ticket dispensers
- Information kiosks
- ATM receipt printing
- Bank counter transaction printing
- Automated queuing terminals
- Lottery ticket terminals
- Gaming voucher printers
- Event entry ticket printers
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | SNR-KP800-TH |
| Product Type | 80mm Auto Cutter Thermal Receipt Printer |
| Printing Technology | Direct thermal line printing |
| Print Resolution | 203 dpi, 8 dots/mm |
| Print Speed | Up to 250mm/s |
| Print Width | 72mm max |
| Paper Width | 60 / 80 / 82.5mm, ±0.5mm |
| Paper Roll Diameter | Up to 150mm |
| Paper Loading | Automatic paper feeding, horizontal 180° |
| Auto Cutter | Yes |
| Cutting Mode | Partial cut / full cut |
| Cutter Life | Over 1.5 million cuts |
| Interfaces | USB, RS232 serial |
| Optional Interfaces | Ethernet, Bluetooth |
| Emulation | ESC/POS compatible |
| Sensors | Paper low, paper end, cover open |
| Operating Voltage | DC24V / 2A |
| Operating Temperature | 0℃ to 50℃ |
| Storage Temperature | -20℃ to 60℃ |
| Dimensions | 231 × 126 × 100mm |
| Weight | Approx. 1.4kg |
| Print Head Life | 150km |
| MTBF | 360,000 hours |
Why Choose SNR-KP800-TH?
SNR-KP800-TH is suitable for projects that require high-speed 80mm receipt printing, long cutter life and stable integration with POS or kiosk systems.
Compared with standard desktop receipt printers, KP800-TH is designed for more demanding commercial and unattended operation. It combines 250mm/s printing, large paper roll support, industrial auto cutter, ESC/POS compatibility, sensor monitoring and multiple interface options.
For retail, hospitality, banking, parking, queuing and self-service applications, SNR-KP800-TH provides a reliable 80mm thermal receipt printer solution with strong performance and easy system integration.
Related Models
SNR-KP805 – 80mm kiosk thermal printer module for banking, parking and queuing systems
SNR-KP800-VX – 80mm kiosk thermal printer for ticket and receipt applications
SNR-KP802-VX – Heavy-duty 80mm kiosk printer for unattended self-service systems
SNR-EP602-TM – 58mm / 60mm embedded thermal printer module for kiosk integration
SNR-KP602-H – 58mm / 60mm high-speed kiosk thermal printer with 250mm/s printing speed
FAQ
What is SNR-KP800-TH used for?
SNR-KP800-TH is used for receipt printing in POS systems, self-service kiosks, retail checkout counters, restaurants, ticketing kiosks, banking terminals, parking systems and queue management terminals.
What is the maximum printing speed?
The maximum printing speed is 250mm/s.
What paper widths are supported?
It supports 60mm, 80mm and 82.5mm thermal paper.
What is the maximum paper roll diameter?
The printer supports paper rolls up to 150mm in diameter.
Does SNR-KP800-TH support auto cutting?
Yes. It includes an industrial auto cutter and supports partial cut or full cut.
What is the cutter lifetime?
The cutter lifetime is over 1.5 million cuts.
What interfaces are available?
Standard interfaces include USB and RS232 serial. Ethernet and Bluetooth are optional.
Is it ESC/POS compatible?
Yes. SNR-KP800-TH is ESC/POS compatible, making it easier to integrate with common POS software and kiosk systems.
Does it support unattended operation?
Yes. It is designed for high-volume and unattended operation, with paper-low, paper-end and cover-open sensors.
What is the print head lifetime?
The print head life is up to 150km.
